Product Description:

This Series of equipment is designed for manufacturing room doors and cupboad plates, which is used for filming the veneer of the door panels. The DP2500 has many functions (cold and hot pressing machine, filming single side or double sides of the wooden door panels and filming PVC doors).
This equipment can glue PVC workpiece firmly together, Never bounce and warp. When manufacturing non-painted or Paint-free doors, it can cut the PVC according to the Door size, so as to save PVC film.

Item data
Overal Dimensioin 2900x1350x2150mm
Workbench Size  2500x960mm
 Maximum Processing thickness  40mm
 Vacuum Pressue  Positive 0.3Mpa,Negative≥-0.09
 Total Power  24kw
 Current consumption  approx. 11kw
 Net weight  3.5MT
 Maxium Temperature  140
